 Posted: 22:51 - 04 Sep 2009  Post subject: Project CBR 600, General Tidyup |
 |
|
After riding 9,000 miles around Europe this summer and taking the bike through some very questionable terrains, it has taken quite a beating. Even before setting of on my trip the cbr was crying for some tlc but unfortunately i had no time.
The bike was dropped once in Spain (side stand on a cobble beach) not the most intelligent thing and once in Marroco whilst my gps took me through what it thought was a road (Infact a dirt track up a mountain). Unfortunately without and crash protectors as i could not afford them at the time.
https://www.bikechatforums.com/files/p1000219.jpg
Pannel was shattered into 5 pieces.
https://www.bikechatforums.com/files/2_177.jpg
Aswell as cosmetics the bike is far due for a service. The oil, filters, pads, chain/sprokets, tyres, battery have all been abused to the point of giving up.
The oil sump is cracked and bodged up with liquid metal.
The chain pretty much died in Spain and had to be adjusted every 100 miles all the way back to the uk to avoid it slipping.
Battery was cooked by bad regulator and lasts minutes with the lights on.
Rear tyre has 3 nails, and was bodged with tyre sealant about 5,000 miles ago.
And much more
Being a student my lack of space and tools has always stopped me from actually attempting any work for myself. So i went out and invested some money into some proper tools. Air compressor, Air tools, Mig Welder, Cordless drill, Dremel multitool, Multimeter, Socket set and so on.
I have only just started today so i will update the thread tomorrow when i get more done. I was not panning to actually post this so only took photo's towards the end of the day when all the work had already been done, so its hard to see just how bad it was before.
Day one.
Parts arrived today. K&N air filter, Oil, Battery, Oil filter, DID chain and sprockets, Crash Mushrooms & Rear Pads.
https://www.bikechatforums.com/files/4_116.jpg
https://www.bikechatforums.com/files/5_190.jpg
https://www.bikechatforums.com/files/6_190.jpg
Rode up to Halfoards in the morning and had them mix paint to match the bike, bought the appropriate thinners, primer so on.
Sand blasted large chunks of rust off subframe, callipers, swing arm and engine bolts.
https://www.bikechatforums.com/files/7_190.jpg
started primering the side pannel.
https://www.bikechatforums.com/files/9_190.jpg
https://www.bikechatforums.com/files/10_190.jpg
Sandblasted rust and dirt off the disks, sandblasting and repainting forks & callipers aswell.
https://www.bikechatforums.com/download.php?id=67715
Started to polish the alternator casing & Rear sets using a dremel wire wheel thing.
https://www.bikechatforums.com/files/8_792.jpg
Epoxied the cracks on the right hand fairing, which was in about 5 pieces now. Applied fibreglass filler to large hole in the fairing. (Old photo, before the extra damage in Europe) Sanded down, added a new layer of general purpose body filler.
https://www.bikechatforums.com/download.php?id=67718
Sanded down again, 80 grit, 240, 800 then 1200. And started applying the first layer of Primer using an airbrush (Takes bloody ages).
https://www.bikechatforums.com/download.php?id=67716
Fitted new battery, Air filter, & balanced the carbs again.
Sandblasted and primered the very rusty swing arm.
https://www.bikechatforums.com/download.php?id=67717
Started rebuilding the exhaust, Drilled out rivets, removed wadding cut out the inner pipe to replace for a stainless straight through. Will try find the right size pipe tomorrow and weld it in there.
https://www.bikechatforums.com/download.php?id=67719
Ok so thats pretty much it for day one. Tomorrow hopefully i will be doing the chain and sprockets, oil sump, rear pads, oil, filters and starting to paint. Hopefully i will also receive the new Double Bubble screen i ordered.
This is the first time i have done any proper work to a bike as i normally just get the garage to do it, so its quite interesting to see what i can get away with doing myself.
Thanks
____________________
CBR1100xx - BMW K1100 - BMW K100 - Triumph Sprint ST 955i - Suzuki GSX-R 600 - Suzuki DR 350 - Yamaha XV 750 - Honda CBR 600 FM - Yamaha XT 600 - Yamaha Rs 200 - Honda NSR 125
Last edited by Raf on 23:22 - 04 Sep 2009; edited 5 times in total |
|
| Back to top |
   |
You must be logged in to rate posts |
|
 |
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Mystery |
This post is not being displayed .
|
Mystery
World Chat Champion
Joined: 23 Jul 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| salty21 |
This post is not being displayed .
|
salty21
World Chat Champion
Joined: 07 Jun 2006
Karma :
|
Posted: 07:00 - 05 Sep 2009  Post subject: |
|
|
did your number's come up or something? must have just spent near on a grand?
____________________
04 NSR 125(sold)  ---- 03 CBR 600rr(sold) ----90 pan euro ST1100 ' ' ----02 CG 125
94 CB400 Super Four ---- 2000 VTR SP1 (sold) ---- 08 ninja p8f(sold, meh) ----05 CBR600rr |
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| ms51ves3 |
This post is not being displayed .
|
ms51ves3
Super Spammer
Joined: 07 Jun 2007
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| mattsprattuk |
This post is not being displayed .
|
mattsprattuk
Super Spammer
Joined: 12 Mar 2007
Karma :
|
| Posted: 09:48 - 05 Sep 2009 Post subject: |
|
|
you should take off parts before shot blasting them. if the grit gets into your bearings (wheel and swingarm) it will mince them pretty quick.
____________________
Blue_SV650S wrote: it was a sh1te wheelie, but it proves that he can get it up in 3rd and can do angles. In summery, mattsprattuk is a gobby little sh1tebag, dopehead tw4t, but sadly for all of us, he probably isn't THAT full of sh1te!!
Kickstart wrote: Hi I tend to agree with Matt. All the best Keith
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| ms51ves3 |
This post is not being displayed .
|
ms51ves3
Super Spammer
Joined: 07 Jun 2007
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| alun111 |
This post is not being displayed .
|
alun111
World Chat Champion
Joined: 31 May 2007
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| tutton |
This post is not being displayed .
|
tutton
World Chat Champion
Joined: 04 Jan 2008
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Mystery |
This post is not being displayed .
|
Mystery
World Chat Champion
Joined: 23 Jul 2009
Karma :
|
| Posted: 22:19 - 05 Sep 2009 Post subject: |
|
|
looks good nice job mate
____________________
Carbon knuckles assure you maximum protect against debris and unfortunate accidents or if someone cuts you off, their side mirror.Mopeds are like chubby chicks.. they are really fun to ride until you're friends catch you on one |
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Steve-D |
This post is not being displayed .
|
Steve-D
World Chat Champion
Joined: 07 Jul 2007
Karma :
|
| Posted: 23:11 - 05 Sep 2009 Post subject: |
|
|
Where abouts are you now? Still in paignton or you moved into your new student house yet.
14 grand Your gonna have a good year.
____________________
www.southwestbikers.com
Tristan The said 'Dunno what my pace will be like, fastish slow puncture on the rear and if I go too fast I risk my 'keys' falling out' |
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Noxious89123 |
This post is not being displayed .
|
Noxious89123
World Chat Champion
Joined: 10 Jun 2007
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| alun111 |
This post is not being displayed .
|
alun111
World Chat Champion
Joined: 31 May 2007
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| geordiecbrblo... |
This post is not being displayed .
|
geordiecbrblo...
Trackday Trickster
Joined: 17 Jul 2005
Karma :
|
| Posted: 15:59 - 08 Sep 2009 Post subject: |
|
|
Looking good, but I'd be tempted to strip the bike a little bit more - am thinking of the swingarm where you have primed over the nut etc and the front brake caliper which you may regret completely spraying over.
No offence meant |
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Noxious89123 |
This post is not being displayed .
|
Noxious89123
World Chat Champion
Joined: 10 Jun 2007
Karma :
|
| Posted: 21:22 - 08 Sep 2009 Post subject: |
|
|
The forks look alot better, but I agree with the previous post, I'm not digging the red calipers.
____________________
'06 Honda CBR125RW-6 ~ '00 Honda CBR600F-Y ~ '07 Honda CBR600RR-7 ~ Bikeless
'53 Ford Ka 1.3 ~ '03 Vauxhall Astra SRi 1.8 ~ '52 Vauxhall Astra SRi 2.2 ~ '53 Vauxhall Astra GSi |
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| Raf |
This post is not being displayed .
|
Raf
Spanner Monkey
Joined: 18 Feb 2009
Karma :
|
|
| Back to top |
| |
You must be logged in to rate posts |
|
|
| serlant |
This post is not being displayed .
|
serlant
Brolly Dolly
Joined: 06 Jul 2009
Karma :
|
| Posted: 18:37 - 12 Sep 2009 Post subject: |
|
|
look loud, nice one  |
|
