*Update 28/07* Project - NSR125 engined C90

[garth]

Hey

I pick this up sunday from hellbound on here. Give him karma, he's a generous man.

https://www.bikechatforums.com/download.php?id=79524

I have an NSR125 engine, carb, loom and spanny in the shed.

I've drawn a little sketch of what I'm going for.

https://img221.imageshack.us/img221/2797/img001ww.jpg

Low, slightly longer than standard, abscence of anything plastic, and with 25+ bhp probably instant suicide. Brapp!
____________________
You ain't a has been if you never was

[Asharin]

Should be interesting!

[hellbound]

I am waiting ridicule as to the state of my garage, lucky only a bit is showing.


And Garth?, You are doing me a favour as it clears a bit of space to fill with more junk!
____________________
May you always see the road rising up to meet you and your enemies defeated in the mirror behind.

[hellbound]

As for suicide I am a bit scared that the front brake is still going to be a drum brake!
____________________
May you always see the road rising up to meet you and your enemies defeated in the mirror behind.

[hazza]

I *THINK* MTX front ends fit on without too much hassle.
____________________
3 Honda NC50's(Sold)-->'72 Puch Maxi S (Sold, want it back!)--> '90 Yamaha RXS 100 (Stolen)--> '87 Honda Cub 90(Sold) --> '95 Kawasaki Eliminator (Sold) --> '98 Bandit 600 (Sold) -->'07 SV650S (Current)

[virus]

[garth]

The leading links are staying, it's character.

I've put H100 forks in a cub before. I may bodge a disc on at some point, I also may put an alloy swinger and 3'' rear rim on it - First things first is get the engine in the frame and lined up.

O and piggyback shocks
____________________
You ain't a has been if you never was

[hellbound]

I was hoping my first "bike" would go to a good home and be looked after................................




















But instead its going to get seriously modified.....WOOHOO!!!!!!!!!!!!!!!!!
____________________
May you always see the road rising up to meet you and your enemies defeated in the mirror behind.

[garth]

https://1.bp.blogspot.com/_Rl4IybrZWF0/TMrW_n9ga4I/AAAAAAAAE2M/1QOb6KhPuVY/s1600/5110103378_882cd2706f_o.jpg

Badman

But more drag racer-ish and less custom.
____________________
You ain't a has been if you never was

[garth]

Well I got the bike back and got it running.

Then this happened.


https://img543.imageshack.us/img543/1222/picture009n.jpg



I need to shave the rear engine mount, chop a little off the frame where the front engine mounts go and fabricate new front mounts.

On the flip side I wont have to extend the frame!
____________________
You ain't a has been if you never was

[pepperami]

loving it already
____________________
I am the sum total of my own existence, what went before makes me who I am now!

[hellbound]

Oh My God!


Looks quite smart actually.


I really ought to find the headlamp/rear lenses and send DVLA Paperwork off


I know, I know, I suck!
____________________
May you always see the road rising up to meet you and your enemies defeated in the mirror behind.

[garth]

Don't need the lenses anymore but thanks! No rush on the paperwork it's not exactly going anywhere is it!

Didn't get anything done this weekend might have a stab tonight at grinding the engine mount down a bit.
____________________
You ain't a has been if you never was

[garth]

Righto. I ground down the rear engine mount, 3.5mm off each side. I then slotted it in the frame and offered it up before cutting away the original c90 frame. The engine now sits much higher in the frame which will help with ground clearance!

https://oi51.tinypic.com/120rq5t.jpg

Chain doesnt look miles away from lining up.

https://oi52.tinypic.com/5k3odt.jpg

Next on the to do list is make up some steel plates for the top engine mount, to weld onto the cub frame. I've provisionally made some templates out of card.

https://oi55.tinypic.com/2e49coy.jpg


And here's one for scale! It's seriously light, you can pick it up easy.

https://img839.imageshack.us/img839/8779/picture015vy.jpg
____________________
You ain't a has been if you never was

[hellbound]

[Teflon-Mike]

https://img543.imageshack.us/img543/1222/picture009n.jpg
With that pressed steel sub frame...
It's just BEGGING for 'streamlining' enclosure...
I kep thinking something like this:-
https://i178.photobucket.com/albums/w269/teflons-torque/XX-Forum%20Posts/Shuttle.jpg
(Gorge Formby, 1935 'No Limit'... film with the song 'When I'm TT-Racing')
____________________
My Webby'Tef's-tQ, loads of stuff about my bikes, my Land-Rovers, and the stuff I do with them!
Current Bikes:'Honda VF1000F' ;'CB750F2N' ;'CB125TD ( 6 3 of em!)'; 'Montesa Cota 248'. Learner FAQ's:= 'U want to Ride a Motorbike! Where Do U start?'

[garth]

Don't see that happening!
____________________
You ain't a has been if you never was

[garth]

Engines in!!

Radiator fits

Still a shit load of work to do!

https://oi54.tinypic.com/2910sy0.jpg


https://oi51.tinypic.com/3095yme.jpg



https://oi53.tinypic.com/2czyo78.jpg
____________________
You ain't a has been if you never was

[pepperami]

This bike is going to be dripping in cool when it`s finished


MOOAAR !
____________________
I am the sum total of my own existence, what went before makes me who I am now!

[Sam_Y_93]

This going to be so awesome when done!
____________________
Bikes Past: Yamaha Aerox (sold) Yamaha R125 (written off)
Bikes Current: Honda VFR 400 (awaiting restoration) Honda CB600f F-4
Theory passed July 21st Mod1 passed August 3rd Mod 2 passed 26th August

[hellbound]

My bike!!!!




























It looks so much better now!
____________________
May you always see the road rising up to meet you and your enemies defeated in the mirror behind.

[hmmmnz]

can you mount the rad even higher? eg the top of it almost touching the frame,
it looks like its floating in mid air,
keep us posted
____________________
the humans are dead
I kick arse for the lord
Wiring Diagrams BIDNIP it bitches

[Frost]

Turn the rad 90 degrees?

[garth]

Rad was only held on by the pipes, I'll mount it so it's got plenty of clearance. But i like it sticking out the sides!
____________________
You ain't a has been if you never was

[TheSmiler]

C90's loads of fond memories with them btw what is the first picture seems like it's not working for me?
____________________
CB125>CG125>GN125>ER5>K100RS>R1100RS>K100RS
A2 completed 23/07/15 Ready for the Golden Crisp Packet
